| DISPLAY |
Panel |
5.4” LTPS |
| Physical Resolution |
1920×1200 |
| Aspect Ratio |
16:10 |
| Brightness |
600cd/㎡ |
| Contrast |
1100:1 |
| Viewing Angle |
160°/ 160° (H/V) |
| HDR |
ST 2084 300/1000/10000 / HLG |
| Supported Log Formats |
Slog2 / Slog3, Arrilog, Clog, Jlog, Vlog, Nlog or User… |
| LUT Support |
3D-LUT (.cube format) |
| INPUT |
3G-SDI |
1 |
| HDMI |
1 (HDMI 2.0, supports up to 4K 60Hz) |
| OUTPUT |
3G-SDI |
1 |
| HDMI |
1 (HDMI 2.0, supports up to 4K 60Hz) |
| FORMATS |
SDI |
1080p 60/50/30/25/24, 1080pSF 30/25/24, 1080i 60/50, 720p 60/50… |
| HDMI |
2160p 60/50/30/25/24, 1080p 60/50/30/25/24, 1080i 60/50, 720p 60/50… |
| AUDIO |
Speaker |
1 |
| Ear Phone Slot |
1 |
| POWER |
Current |
0.75A (12V) |
| Input Voltage |
DC 7-24V |
| Battery Plate |
NP-F / LP-E6 |
| Power Consumption |
≤9W |
| ENVIRONMENT |
Operating Temperature |
-20℃~50℃ |
| Storage Temperature |
-30℃~70℃ |
| DIMENSION |
Dimension(LWD) |
154.5×90×20mm |
| Weight |
295g |
